Hallo
Mein Experiment fing vor einem Jahr an, als meine Frau auf mich zukam und meinte âIch will wieder eine Uhr im Bad und sehen wie die Zeit meiner ZahnbĂŒrste istâ Der Grund dieser Anforderung war das wir frĂŒher die OralB Pro hatten und da gab es solch ein Teil dazu
Die neuen iO haben sowas nicht. Der erste Versuch war das hier, wo ich mich ewig und 3 Tage mit der ESP-IDF IDE gequÀlt hab und das Template von SeeedStudio umgebaut hab.
NunâŠ10 Monate spĂ€ter hat ESPHome alles was es braucht um ohne Umwege ĂŒber MQTT/OpenHASP, Espressif-IDE oder Ă€hnliches, sich schöne Touchscreens zu bauen. Einige Display-Treiber sind dazu gekommen unter anderem fĂŒr den Sensecap Indicator, neue Touchscreen Treiber und letztendlich: native LVGL UnterstĂŒtzung
Jetzt musste ein 2. Sensecap her, ich wollte das produktive Teil ja nicht ruinieren
In einem ersten Wurf, um gefĂŒhlt Jahre schneller entwickelt, mit mehr Comfort, kam das dabei raus (da kommt noch die Lichtsteuerung etc gleich mit rein)
Wir haben die gewĂŒnschte Uhr, jetzt auch mit den AkkustĂ€nden der beiden OralB, wenn jemand anfĂ€ngt zu putzen, schaltet das Display um und nach 5min wieder zurĂŒck auf die Uhr.
Nebenbei ist das Design an unseren anderen Dashboards angelehnt. Nur das Blurring gibts noch nicht.
Ich kipp einfach mal den Code, soweit wie ich jetzt bin mal hier rein und darunter kommen viele Links
esphome:
name: dev-sensecapindicator
friendly_name: DEV-SensecapIndicator
platformio_options:
build_unflags: -Werror=all
esp32:
board: esp32-s3-devkitc-1
variant: esp32s3
flash_size: 8MB
framework:
type: esp-idf
version: 5.2.2
platform_version: 6.7.0
sdkconfig_options:
CONFIG_ESPTOOLPY_FLASHSIZE_8MB: y
CONFIG_ESP32S3_DEFAULT_CPU_FREQ_240: y
CONFIG_ESP32S3_DATA_CACHE_64KB: y
CONFIG_SPIRAM_FETCH_INSTRUCTIONS: y
CONFIG_SPIRAM_RODATA: y
psram:
mode: octal
speed: 80MHz
# Enable logging
logger:
level: DEBUG
# Enable Home Assistant API
api:
encryption:
key: "xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx"
ota:
- platform: esphome
password: "xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx"
wifi:
networks:
- ssid: !secret wifi_ssid_UGV2
password: !secret wifi_password_UGV2
hidden: True
# Enable fallback hotspot (captive portal) in case wifi connection fails
ap:
ssid: "DEV-SensecapIndicator"
password: !secret wifi_password_fallback
captive_portal:
time:
- platform: sntp
id: sntp_time
timezone: Europe/Zurich
servers:
- 192.168.166.1 #mein Router, falls das Internet mal Pause macht
on_time_sync:
- script.execute: time_update
on_time:
- minutes: '*'
seconds: 0
then:
- script.execute: time_update
script:
- id: time_update
then:
- lvgl.label.update:
id: lvgl_clock_minute
text:
format: "%02d"
args: [ 'id(sntp_time).now().minute' ]
- lvgl.label.update:
id: lvgl_clock_hour
text:
format: "%02d"
args: [ 'id(sntp_time).now().hour' ]
- lvgl.label.update:
id: lvgl_clock_longdate
text:
format: "%s, %02d.%02d.%04d"
args:
- '(new const char *[7]{"Sunntig", "MÀÀntig", "Ziischtig", "Mittwuch", "Dunschtig", "Friitig", "Samschtig"})[id(sntp_time).now().day_of_week-1]'
- 'id(sntp_time).now().day_of_month'
- 'id(sntp_time).now().month'
- 'id(sntp_time).now().year'
- id: back_to_timepage
mode: restart
then:
- delay: 5 min
- lvgl.page.show: page_time
text_sensor:
- platform: wifi_info
ssid:
name: SSID
bssid:
name: BSSID
- platform: homeassistant
name: "papi_Mode"
entity_id: sensor.oralb_papi_mode
id: papi_mode
internal: true
on_value:
- lvgl.label.update:
id: lvgl_papi_mode
text:
format: "%s"
args: [ 'id(papi_mode).state.c_str()' ]
- platform: homeassistant
name: "mami_Mode"
entity_id: sensor.oralb_mami_mode
id: mami_mode
internal: true
on_value:
- lvgl.label.update:
id: lvgl_mami_mode
text:
format: "%s"
args: [ 'id(mami_mode).state.c_str()' ]
- platform: homeassistant
name: "papi_Pressure"
entity_id: sensor.oralb_papi_pressure
id: papi_pressure
internal: true
on_value:
- lvgl.label.update:
id: lvgl_papi_pressure
text:
format: "%s"
args: [ 'id(papi_pressure).state.c_str()' ]
- platform: homeassistant
name: "mami_Pressure"
entity_id: sensor.oralb_mami_pressure
id: mami_pressure
internal: true
on_value:
- lvgl.label.update:
id: lvgl_mami_pressure
text:
format: "%s"
args: [ 'id(mami_pressure).state.c_str()' ]
- platform: homeassistant
name: "papi_State"
entity_id: sensor.oralb_papi_toothbrush_state
id: papi_state
internal: true
- platform: homeassistant
name: "mami_State"
entity_id: sensor.oralb_mami_toothbrush_state
id: mami_state
internal: true
- platform: homeassistant
name: "papi_Sector"
entity_id: sensor.oralb_papi_sector
id: papi_sector
internal: true
on_value:
- lvgl.label.update:
id: lvgl_papi_sector
text:
format: "%s"
args: [ 'id(papi_sector).state.c_str()' ]
- platform: homeassistant
name: "mami_Sector"
entity_id: sensor.oralb_mami_sector
id: mami_sector
internal: true
on_value:
- lvgl.label.update:
id: lvgl_mami_sector
text:
format: "%s"
args: [ 'id(mami_sector).state.c_str()' ]
sensor:
- platform: wifi_signal
id: wifi_signal_db
name: "WiFi Signal"
update_interval: 60s
- platform: copy
id: wifi_signal_percent
source_id: wifi_signal_db
internal: true
name: "WiFi Signal Percent"
filters:
- lambda: return min(max(2 * (x + 100.0), 0.0), 100.0);
on_value:
- lvgl.label.update:
id: lvgl_wifi_signal_percent
text:
format: "%.0f%%"
args: [ 'id(wifi_signal_percent).get_state()' ]
- lvgl.label.update:
id: lvgl_wifi_signal_percent_icon
text: !lambda |-
static char buf[10];
std::string icon;
if (x == 100.0) {
icon = "\U000F0928";
} else if (x > 75) {
icon = "\U000F0925";
} else if (x > 50) {
icon = "\U000F0922";
} else if (x > 25) {
icon = "\U000F091F";
} else {
icon = "\U000F092F";
}
snprintf(buf, sizeof(buf), "%s", icon.c_str());
return buf;
- platform: homeassistant
name: "papi_Battery"
entity_id: sensor.oralb_papi_battery
id: papi_battery
internal: true
on_value:
- lvgl.label.update:
id: lvgl_papi_battery
text:
format: "%.0f %%"
args: [ 'id(papi_battery).get_state()' ]
- lvgl.label.update:
id: lvgl_papi_battery_front
text:
format: "%.0f%%"
args: [ 'id(papi_battery).get_state()' ]
- lvgl.label.update:
id: lvgl_papi_battery_icon
text: !lambda |-
static char buf[10];
std::string icon;
if (x == 100.0) {
icon = "\U000F0948"; // mdi-battery (full)
} else if (x > 90) {
icon = "\U000F0946"; // mdi-battery-90
} else if (x > 80) {
icon = "\U000F0945"; // mdi-battery-80
} else if (x > 70) {
icon = "\U000F0944"; // mdi-battery-70
} else if (x > 60) {
icon = "\U000F0943"; // mdi-battery-60
} else if (x > 50) {
icon = "\U000F0942"; // mdi-battery-50
} else if (x > 40) {
icon = "\U000F0941"; // mdi-battery-40
} else if (x > 30) {
icon = "\U000F0940"; // mdi-battery-30
} else if (x > 20) {
icon = "\U000F093F"; // mdi-battery-20
} else if (x > 10) {
icon = "\U000F093E"; // mdi-battery-10
} else if (x > 0) {
icon = "\U000F10CD"; // mdi-battery-outline
} else {
icon = "\U000F10CD"; // mdi-battery-unknown
}
snprintf(buf, sizeof(buf), "%s", icon.c_str());
return buf;
- lvgl.label.update:
id: lvgl_papi_battery_front_icon
text: !lambda |-
static char buf[10];
std::string icon;
if (x == 100.0) {
icon = "\U000F0948"; // mdi-battery (full)
} else if (x > 90) {
icon = "\U000F0946"; // mdi-battery-90
} else if (x > 80) {
icon = "\U000F0945"; // mdi-battery-80
} else if (x > 70) {
icon = "\U000F0944"; // mdi-battery-70
} else if (x > 60) {
icon = "\U000F0943"; // mdi-battery-60
} else if (x > 50) {
icon = "\U000F0942"; // mdi-battery-50
} else if (x > 40) {
icon = "\U000F0941"; // mdi-battery-40
} else if (x > 30) {
icon = "\U000F0940"; // mdi-battery-30
} else if (x > 20) {
icon = "\U000F093F"; // mdi-battery-20
} else if (x > 10) {
icon = "\U000F093E"; // mdi-battery-10
} else if (x > 0) {
icon = "\U000F10CD"; // mdi-battery-outline
} else {
icon = "\U000F10CD"; // mdi-battery-unknown
}
snprintf(buf, sizeof(buf), "%s", icon.c_str());
return buf;
- platform: homeassistant
name: "mami_Battery"
entity_id: sensor.oralb_mami_battery
id: mami_battery
internal: true
on_value:
- lvgl.label.update:
id: lvgl_mami_battery
text:
format: "%.0f %%"
args: [ 'id(mami_battery).get_state()' ]
- lvgl.label.update:
id: lvgl_mami_battery_front
text:
format: "%.0f%%"
args: [ 'id(mami_battery).get_state()' ]
- lvgl.label.update:
id: lvgl_mami_battery_icon
text: !lambda |-
static char buf[10];
std::string icon;
if (x == 100.0) {
icon = "\U000F0948"; // mdi-battery (full)
} else if (x > 90) {
icon = "\U000F0946"; // mdi-battery-90
} else if (x > 80) {
icon = "\U000F0945"; // mdi-battery-80
} else if (x > 70) {
icon = "\U000F0944"; // mdi-battery-70
} else if (x > 60) {
icon = "\U000F0943"; // mdi-battery-60
} else if (x > 50) {
icon = "\U000F0942"; // mdi-battery-50
} else if (x > 40) {
icon = "\U000F0941"; // mdi-battery-40
} else if (x > 30) {
icon = "\U000F0940"; // mdi-battery-30
} else if (x > 20) {
icon = "\U000F093F"; // mdi-battery-20
} else if (x > 10) {
icon = "\U000F093E"; // mdi-battery-10
} else if (x > 0) {
icon = "\U000F10CD"; // mdi-battery-outline
} else {
icon = "\U000F10CD"; // mdi-battery-unknown
}
snprintf(buf, sizeof(buf), "%s", icon.c_str());
return buf;
- lvgl.label.update:
id: lvgl_mami_battery_front_icon
text: !lambda |-
static char buf[10];
std::string icon;
if (x == 100.0) {
icon = "\U000F0948"; // mdi-battery (full)
} else if (x > 90) {
icon = "\U000F0946"; // mdi-battery-90
} else if (x > 80) {
icon = "\U000F0945"; // mdi-battery-80
} else if (x > 70) {
icon = "\U000F0944"; // mdi-battery-70
} else if (x > 60) {
icon = "\U000F0943"; // mdi-battery-60
} else if (x > 50) {
icon = "\U000F0942"; // mdi-battery-50
} else if (x > 40) {
icon = "\U000F0941"; // mdi-battery-40
} else if (x > 30) {
icon = "\U000F0940"; // mdi-battery-30
} else if (x > 20) {
icon = "\U000F093F"; // mdi-battery-20
} else if (x > 10) {
icon = "\U000F093E"; // mdi-battery-10
} else if (x > 0) {
icon = "\U000F10CD"; // mdi-battery-outline
} else {
icon = "\U000F10CD"; // mdi-battery-unknown
}
snprintf(buf, sizeof(buf), "%s", icon.c_str());
return buf;
- platform: homeassistant
name: "papi_Timer"
entity_id: sensor.oralb_papi_timer
id: papi_timer
internal: true
on_value:
- lvgl.label.update:
id: lvgl_papi_timer
text:
format: "%.0f"
args: [ 'id(papi_timer).get_state()' ]
- lvgl.bar.update:
id: lvgl_papi_bar
value: !lambda |-
return id(papi_timer).get_state();
- if:
condition:
lambda: |-
return x == 1;
then:
- lvgl.page.show:
id: page_oralb
- script.execute: back_to_timepage
- platform: homeassistant
name: "mami_Timer"
entity_id: sensor.oralb_mami_timer
id: mami_timer
internal: true
on_value:
- lvgl.label.update:
id: lvgl_mami_timer
text:
format: "%.0f"
args: [ 'id(mami_timer).get_state()' ]
- lvgl.bar.update:
id: lvgl_mami_bar
value: !lambda |-
return id(mami_timer).get_state();
- if:
condition:
lambda: |-
return x == 1;
then:
- lvgl.page.show:
id: page_oralb
- script.execute: back_to_timepage
binary_sensor:
- platform: gpio
internal: true
id: sensecap_greenbutton
name: "Green Button"
pin:
number: GPIO38
inverted: yes
mode:
input: true
pullup: true
on_press:
then:
- light.toggle: sensecap_display_backlight
output:
- platform: ledc
pin:
number: GPIO45
ignore_strapping_warning: true
id: ledc_gpio45
frequency: 100Hz
light:
- platform: monochromatic
output: ledc_gpio45
name: Display Backlight
id: sensecap_display_backlight
internal: true
restore_mode: ALWAYS_ON
i2c:
- id: bus_a
sda: GPIO39
scl: GPIO40
scan: false
spi:
- id: lcd_spi
clk_pin: GPIO41
mosi_pin: GPIO48
pca9554:
- id: pca9554a_device
address: 0x20
pin_count: 16
touchscreen:
platform: ft5x06
id: sensecap_touchscreen
transform:
mirror_x: true
mirror_y: true
display:
- platform: st7701s
id: sensecap_display
auto_clear_enabled: false
data_rate: 4MHz
update_interval: never
spi_mode: MODE3
color_order: RGB
dimensions:
width: 480
height: 480
invert_colors: true
transform:
mirror_x: true
mirror_y: true
cs_pin:
pca9554: pca9554a_device
number: 4
reset_pin:
pca9554: pca9554a_device
number: 5
de_pin: GPIO18
hsync_pin: GPIO16
vsync_pin: GPIO17
pclk_pin: GPIO21
init_sequence:
- 1 # select canned init sequence number 1
- delay 5ms
- [ 0xE0, 0x1F ] # Set sunlight readable enhancement
data_pins:
red:
- GPIO4 #r1
- GPIO3 #r2
- GPIO2 #r3
- GPIO1 #r4
- GPIO0 #r5
green:
- GPIO10 #g0
- GPIO9 #g1
- GPIO8 #g2
- GPIO7 #g3
- GPIO6 #g4
- GPIO5 #g5
blue:
- GPIO15 #b1
- GPIO14 #b2
- GPIO13 #b3
- GPIO12 #b4
- GPIO11 #b5
font:
- file:
type: gfonts
family: Roboto
weight: 400
id: roboto14
size: 14
bpp: 4
glyphs: '!"%()+=,-_.:°/?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZĂĂĂ abcdefghijklmnopqrstuvwxyzĂ€Ă¶ĂŒ'
- file:
type: gfonts
family: Roboto
weight: 400
id: roboto16
size: 16
bpp: 4
glyphs: '!"%()+=,-_.:°/?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZĂĂĂ abcdefghijklmnopqrstuvwxyzĂ€Ă¶ĂŒ'
- file:
type: gfonts
family: Roboto
weight: 400
id: roboto18
size: 18
bpp: 4
glyphs: '!"%()+=,-_.:°/?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZĂĂĂ abcdefghijklmnopqrstuvwxyzĂ€Ă¶ĂŒ'
- file:
type: gfonts
family: Roboto
weight: 400
id: roboto22
size: 22
bpp: 4
glyphs: '!"%()+=,-_.:°/?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZĂĂĂ abcdefghijklmnopqrstuvwxyzĂ€Ă¶ĂŒ'
- file:
type: gfonts
family: Roboto
weight: 400
id: roboto48
size: 48
bpp: 4
glyphs: '0123456789'
- file:
type: gfonts
family: Roboto
weight: 700
id: robotobold140
size: 140
bpp: 4
glyphs: '0123456789'
- file:
type: gfonts
family: Roboto
weight: 700
id: robotobold96
size: 96
bpp: 4
glyphs: ':'
- file: "https://github.com/Templarian/MaterialDesign-Webfont/raw/master/fonts/materialdesignicons-webfont.ttf"
id: icons32
size: 32
bpp: 4
glyphs: [
"\U000F1AE1", # mdi:timer-play-outline
"\U000F01FB", # mdi:engine-outline
"\U000F0199", # mdi:counter
"\U000F029A", # mdi:gauge
"\U000F092F", # mdi:wifi-strength-outline
"\U000F091F", # mdi:wifi-strength-1
"\U000F0922", # mdi:wifi-strength-2
"\U000F0925", # mdi:wifi-strength-3
"\U000F0928", # mdi:wifi-strength-4
"\U000F02FD", # mdi:information-outline
"\U000F093E", # mdi:battery-10-bluetooth
"\U000F093F", # mdi:battery-20-bluetooth
"\U000F0940", # mdi:battery-30-bluetooth
"\U000F0941", # mdi:battery-40-bluetooth
"\U000F0942", # mdi:battery-50-bluetooth
"\U000F0943", # mdi:battery-60-bluetooth
"\U000F0944", # mdi:battery-70-bluetooth
"\U000F0945", # mdi:battery-80-bluetooth
"\U000F0946", # mdi:battery-90-bluetooth
"\U000F0948", # mdi:battery-bluetooth
"\U000F10CD", # mdi:battery-alert-variant-outline
]
- file: "https://github.com/Templarian/MaterialDesign-Webfont/raw/master/fonts/materialdesignicons-webfont.ttf"
id: icons24
size: 24
bpp: 4
glyphs: [
"\U000F092F", # mdi:wifi-strength-outline
"\U000F091F", # mdi:wifi-strength-1
"\U000F0922", # mdi:wifi-strength-2
"\U000F0925", # mdi:wifi-strength-3
"\U000F0928", # mdi:wifi-strength-4
"\U000F093E", # mdi:battery-10-bluetooth
"\U000F093F", # mdi:battery-20-bluetooth
"\U000F0940", # mdi:battery-30-bluetooth
"\U000F0941", # mdi:battery-40-bluetooth
"\U000F0942", # mdi:battery-50-bluetooth
"\U000F0943", # mdi:battery-60-bluetooth
"\U000F0944", # mdi:battery-70-bluetooth
"\U000F0945", # mdi:battery-80-bluetooth
"\U000F0946", # mdi:battery-90-bluetooth
"\U000F0948", # mdi:battery-bluetooth
"\U000F10CD", # mdi:battery-alert-variant-outline
]
image:
- file: 'lvgl/sensecap_wp1.png'
id: wallpaper
resize: 480x480
type: RGB565
use_transparency: true
lvgl:
displays:
- sensecap_display
touchscreens:
- sensecap_touchscreen
disp_bg_image: wallpaper
style_definitions:
- id: panelwithouttimer
width: 190
height: 65
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
- id: label_icon
x: 10
y: 16
width: 32
height: 32
text_color: 0xFFFFFF
text_font: icons32
text_align: LEFT
- id: label_name
x: 55
y: 9
text_color: 0xC4C4C4
text_font: roboto16
text_align: LEFT
- id: label_value
x: 55
y: 30
text_color: 0xFFFFFF
text_font: roboto18
text_align: LEFT
pages:
- id: page_time
bg_color: 0x16417d
bg_opa: TRANSP
widgets:
- obj:
x: -142
y: 10
align: TOP_MID
width: 135
height: 41
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 20
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 15
y: 6
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: icons24
text_align: LEFT
id: lvgl_mami_battery_front_icon
text: "\U000F10CD"
- label:
x: 45
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
text: "Mami"
- label:
x: 85
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
id: lvgl_mami_battery_front
text: "--%"
- obj:
x: 2
y: 10
align: TOP_MID
width: 125
height: 41
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 20
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 15
y: 6
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: icons24
text_align: LEFT
id: lvgl_papi_battery_front_icon
text: "\U000F10CD"
- label:
x: 45
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
text: "Papi"
- label:
x: 80
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
id: lvgl_papi_battery_front
text: "--%"
- obj:
x: 145
y: 10
align: TOP_MID
width: 130
height: 41
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 20
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 15
y: 6
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: icons24
text_align: LEFT
id: lvgl_wifi_signal_percent_icon
text: "\U000F092F"
- label:
x: 45
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
text: "WiFi"
- label:
x: 80
y: 11
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto14
text_align: LEFT
id: lvgl_wifi_signal_percent
text: "--%"
- label:
id: lvgl_clock_longdate
x: 40
y: 110
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: roboto22
text_align: LEFT
text: " "
- obj:
x: -110
y: 0
align: CENTER
width: 190
height: 170
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
id: lvgl_clock_hour
x: 0
y: 0
align: CENTER
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: robotobold140
text_align: CENTER
text: "00"
- obj:
x: 110
y: 0
align: CENTER
width: 190
height: 170
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
id: lvgl_clock_minute
x: 0
y: 0
align: CENTER
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: robotobold140
text_align: CENTER
text: "00"
- label:
x: 0
y: 0
align: CENTER
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: robotobold96
text_align: CENTER
text: ":"
- id: page_oralb
bg_color: 0xFFFFFF
bg_opa: TRANSP
widgets:
- obj:
x: 40
y: 20
width: 190
height: 40
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 5
y: 7
width: 180
height: 30
text_color: 0xFFFFFF
text_font: roboto18
text_align: CENTER
text: "Papi"
- obj:
x: 250
y: 20
width: 190
height: 40
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 5
y: 7
width: 180
height: 30
text_color: 0xFFFFFF
text_font: roboto18
text_align: CENTER
text: "Mami"
- obj:
x: 40
y: 70
width: 190
height: 90
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 7
y: 20
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: icons32
text_align: LEFT
text: "\U000F1AE1"
- label:
id: lvgl_papi_timer
x: 40
y: 7
width: 90
text_color: 0xFFFFFF
text_font: roboto48
text_align: RIGHT
text: "--"
- label:
x: 140
y: 30
text_color: 0xFFFFFF
text_font: roboto22
text: "sek"
- bar:
x: 15
y: 65
height: 10
width: 160
id: lvgl_papi_bar
min_value: 0
max_value: 180
bg_color: 0x363636
bg_opa: 40%
indicator:
bg_color: 0xFF0000
bg_opa: 80%
bg_grad_color: 0x00FF00
bg_grad_dir: HOR
- obj:
x: 250
y: 70
width: 190
height: 90
border_color: 0xFFFFFF
border_width: 2
border_opa: 30%
bg_color: 0x16417d
bg_opa: 30%
radius: 4
scrollbar_mode: "off"
pad_all: 0
widgets:
- label:
x: 7
y: 20
width: SIZE_CONTENT
height: SIZE_CONTENT
text_color: 0xFFFFFF
text_font: icons32
text_align: LEFT
text: "\U000F1AE1"
- label:
id: lvgl_mami_timer
x: 40
y: 7
width: 90
text_color: 0xFFFFFF
text_font: roboto48
text_align: RIGHT
text: "--"
- label:
x: 140
y: 30
text_color: 0xFFFFFF
text_font: roboto22
text: "sek"
- bar:
x: 15
y: 65
height: 10
width: 160
id: lvgl_mami_bar
min_value: 0
max_value: 180
bg_color: 0x363636
bg_opa: 40%
indicator:
bg_color: 0xFF0000
bg_opa: 80%
bg_grad_color: 0x00FF00
bg_grad_dir: HOR
- obj:
x: 40
y: 170
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F01FB"
- label:
styles: label_name
text: "Reinigung"
- label:
id: lvgl_papi_mode
styles: label_value
text: "--"
- obj:
x: 250
y: 170
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F01FB"
- label:
styles: label_name
text: "Reinigung"
- label:
id: lvgl_mami_mode
styles: label_value
text: "--"
- obj:
x: 40
y: 245
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F0199"
- label:
styles: label_name
text: "Sektor"
- label:
id: lvgl_papi_sector
styles: label_value
text: "--"
- obj:
x: 250
y: 245
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F0199"
- label:
styles: label_name
text: "Sektor"
- label:
id: lvgl_mami_sector
styles: label_value
text: "--"
- obj:
x: 40
y: 320
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F029A"
- label:
styles: label_name
text: "BĂŒrstendruck"
- label:
id: lvgl_papi_pressure
styles: label_value
text: "--"
- obj:
x: 250
y: 320
styles: panelwithouttimer
widgets:
- label:
styles: label_icon
text: "\U000F029A"
- label:
styles: label_name
text: "BĂŒrstendruck"
- label:
id: lvgl_mami_pressure
styles: label_value
text: "--"
- obj:
x: 40
y: 395
styles: panelwithouttimer
widgets:
- label:
id: lvgl_papi_battery_icon
styles: label_icon
text: "\U000F0948"
- label:
styles: label_name
text: "Batteriestand"
- label:
id: lvgl_papi_battery
styles: label_value
text: "--"
- obj:
x: 250
y: 395
styles: panelwithouttimer
widgets:
- label:
id: lvgl_mami_battery_icon
styles: label_icon
text: "\U000F0948"
- label:
styles: label_name
text: "Batteriestand"
- label:
id: lvgl_mami_battery
styles: label_value
text: "--"
ESPHome LVGL Graphics
ESPHome LVGL Tipps
ESPHome LVGL Widgets
GitHub LVGL Esphome Samples (glĂŒcklicherweise fĂŒr den Sensecap)
HA Forum LVGL auf einem Guition 4" Display
FĂŒr Designer gibts noch das Squareline Studio https://squareline.io/, bei Registration gibts eine Einzel-Lizenz. Damit hab ich das Design fĂŒr Espressif gemacht, es ist nur bedingt fĂŒr ESPHome geeignet da es keinen Yaml-Code ausspuckt, aber um die ganzen Koordinaten schon zu haben und die Möglichkeiten auszuschöpfen ist es allemal gut.
NunâŠviel Spass beim DesignenâŠ
